Range Vent Hood Parts and Repair Troubleshooting Advice
by 411 on Mar 29, 2017
What is Wrong with Your Range Vent Hood? Let's look at some troubleshooting your vent including if the fan doesn't work, the light isn't working, fan issues, and replacement instructions. By "vent hood" we mean the vent hood unit that may be above your stove/range. We're not talking, here, about down-draft systems, a system that's integrated into your microwave, a pop-up system, or a specialty slide-out unit.
The fan doesn't work
The light doesn't work
It doesn't work at all
The fan runs at only one speed
The light dimmer doesn't work
The fan circulates the air but doesn't vent outside
Learn more about range vents
Order replacement parts
Note: If your repair problem isn't listed, click here to email or chat with a repair expert.
The fan doesn't work
If the fan doesn't work but the light does work, you probably have either a defective fan switch or a burned-out fan motor. You can replace either one without removing the vent hood from the wall, but you need to use an ohmmeter to decide which component is defective.
The fan switch should have 0 ohms of resistance when switched on. If it doesn't, replace the switch. If it does, you need to replace the fan motor.
The light doesn't work
When the light doesn't work, it's usually because the bulb has burned out. If you replace the bulb and the light still doesn't work but the fan does work, either the light switch or the lamp-holder socket is defective. You can replace either of these without removing the vent hood from the wall.
It doesn't work at all
Your vent hood is normally wired directly to your household electrical system (you don't plug it in). If the unit doesn't work at all, check for a blown fuse or a tripped circuit breaker.
The fan runs at only one speed
When your fan runs at only one speed, it's either because of a partially defective fan motor or a defective fan switch. You can replace either of these without removing the vent hood from the wall, but you need to use an ohmmeter to decide which component is defective.
The fan switch should have 0 ohms of resistance when switched on. If it doesn't, replace the switch. If it does, you need to replace the fan motor.
The light dimmer doesn't work
If your vent hood has a dimmer switch that adjusts the light intensity, but the dimmer doesn't work, the dimmer switch is probably defective. If so, you need to replace it.
The fan circulates the air but doesn't vent outside
Your vent hood may be one of the many that are meant to circulate the air but not remove it. Here's how you can tell:
- If your unit has vent openings near the top, front of the unit, and the air is blowing through these vents, you have a circulate-only type of hood.
- If, when you check inside the cabinet above the vent hood, you see a metal duct leading away from the vent hood, you have a venting type. But if there's no duct, your unit may still vent through the back wall.
It's difficult to convert a circulating ventilation system so that it vents outside. You would need to run a metal duct from the vent hood either to an outside wall or through the roof of the house. We suggest you contact a qualified appliance installer, to determine whether a duct can be installed in your home.
Work on these areas of an appliance may require help from an appliance repair person or other qualified technicians.
Warning! To avoid personal injury or even death, always disconnect your appliance from its power source--that is, unplug it or break the connection at the circuit breaker or fuse box--before you do any troubleshooting or repair work on your appliance. Also, because some components may have sharp edges, use caution while working on your appliance.
